Ultrasonic Level Meter
  • Ultrasonic Level Meter
  • Ultrasonic Level Meter
  • Ultrasonic Level Meter
  • Ultrasonic Level Meter
  • Ultrasonic Level Meter
  • Ultrasonic Level Meter

Ultrasonic Level Meter

Changzhou Wheat Automation Technology CO.,LTD is a high-tech company engaged in electronic products . The company was established in May 2012, has many famous enterprises at home and abroad to establish a long-term friendly business relationship. Company mainly engaged in electronic products,Such as :Laser distance sensor, temperature sensor, Ultrasonic Level Meter, Isolator…

Запросить сейчас Никто
{：L('RNSHARE')}
  • Описание
  • Параметры
  • Фото оборудования

Changzhou Wheat Automation Technology CO.,LTD is a high-tech company engaged in electronic products . The company was established in May 2012, has many famous enterprises at home and abroad to establish a long-term friendly business relationship. Company mainly engaged in electronic products,Such as :Laser distance sensor, temperature sensor, Ultrasonic Level Meter, Isolator…

Changzhou Wheat Automation Technology CO.,LTD is a high-tech company engaged in electronic products . The company was established in May 2012, has many famous enterprises at home and abroad to establish a long-term friendly business relationship. Company mainly engaged in electronic products,Such as :Laser distance sensor, temperature sensor, Ultrasonic Level Meter, Isolator…

FunctionIntegrated TypeSeparate Type
Measuring range

5M: WA-UI5-485,  WA-UI5-23210m:WA-UI10-485, WA-UI10-23215m:WA-UI15-485, WA-UI15-23220m: WA-UI20-485, WA-UI20-23230m,:WA-UI30-485, WA-UI30-23240m: WA-UI40-485, WA-UI40-23250m: WA-UI50-485, WA-UI50-23260m: WA-UI60-485, WA-UI60-232

5m:  WA-US5-485, WA-US5-23210m:WA-US5-485, WA-US5-23215m:WA-US5-485, WA-US5-23220m:WA-US5-485, WA-US5-23230m:WA-US5-485, WA-US5-23240m:WA-US5-485, WA-US5-23250m:WA-US5-485, WA-US5-23260m:WA-US5-485, WA-US5-23270M: WA-US5-485, WA-US5-232
Measurement accuracy0.5%-1.0%0.5%-1.0%
Resolution ratio3mm or 0.1% (whichever is greater)3mm or 0.1% (whichever is greater)
DisplayEnglish LCDEnglish LCD
Analog output4-line system, 4~20mA/ 510Ω load2-line system, 4~20mA/ 250Ω load4~20mA/ 510Ω load
Relay output2 groups (i.e. AC 250V/ 8A or  DC 30V/ 5A) optional, state programmable2 groups for single channel and 4 groups for double channels (optional) AC 250V/ 8A or DC 30V/ 5A, state programmable
Power supplyStandard configuration: 24VDCOptional: 220V AC+15%  50HzStandard configuration: 220V AC+15%  50HzOptional: 24VDC 120mA Customized: 12VDC or battery powered
Ambient temperatureDisplay instrument: -20~+60ºCProbe: -20~+80ºCDisplay instrument: -20~+60ºCProbe: -20~+80ºC
Communication485, 232 communication (optional) (manufacturer agreement)485, 232 communication (optional) (manufacturer agreement)
IP gradeDisplay instrument: IP65, probe: IP68Display instrument: IP65, probe: IP68
Probe cableNone100m available, standard configuration: 10m
Probe installationSelect type based on measuring range and probeSelect type based on measuring range and probe
